11 Oct Harman Kardon PM 660

Posted at 22:29h in All stock, Amplifiers by
0 Likes

STEREO INTEGRATED AMPLIFIER

190eur

General
Manufacturer: Harman Kardon
Model: PM 660
Year of manufacture: 1983–1984
Made in: Japan
Dimensions: 440 × 122 × 360 mm
Weight: approx. 12.1 kg

Technical Data
Type: Solid-state stereo integrated amplifier
Power output: 80 W per channel at 8 Ω
Total harmonic distortion: 0.06%
Frequency response: 0.5 Hz – 140 kHz (−3 dB)
Signal-to-Noise Ratio: 80 dB (line), 78 dB (phono)
Slew rate: 100 V/µs
Phono inputs: MM and MC
Inputs: Phono, tuner, AUX, tape 1, tape 2
Outputs: Speaker terminals, tape recording outputs
Speaker connections: Two pairs of speakers
Power consumption: 328 W

Special Features
– High-current capability design for driving demanding loudspeakers
– Dedicated MM/MC phono stage for connecting turntables
– Adjustable phono capacitance for cartridge matching
– Main Direct switch bypasses tone and balance control circuitry
– Bass and treble controls with tone defeat function
– Loudness compensation for low-volume listening
– Subsonic and high-cut filters
– Audio mute function with −20 dB attenuation
– Tape dubbing and recording selector for two tape decks
