11 Oct Onkyo SC-600

Posted at 23:17h in All stock, Loudspeakers by
0 Likes

3-WAY PASSIVE LOUDSPEAKERS

210eur

General
Manufacturer: Onkyo
Model: SC-600
Year of manufacture: 1981
Made in: Japan
Type: Passive loudspeaker system
Enclosure type: Acoustic suspension (sealed enclosure)
Dimensions: 322 × 578 × 336 mm
Weight: approx. 17 kg per speaker

Technical Data
Configuration: 3-way, 3-driver
Power handling: 80 W nominal, 120 W music power
Recommended amplifier power: 40–120 W
Nominal impedance: 6 Ω
Frequency response: 30 Hz – 70 kHz
Low-frequency driver: 280 mm cone woofer
Midrange driver: 100 mm carbon cone
High-frequency driver: 30 mm radial ribbon tweeter
Crossover network: Passive 3-way
Connections: Speaker terminals

Special Features
– Three-way design with dedicated bass, midrange and high-frequency drivers
– Large 280 mm woofer for extended low-frequency reproduction
– Carbon-cone midrange driver for detailed vocal and instrumental reproduction
– Radial ribbon tweeter designed for high-frequency clarity
– Sealed acoustic enclosure for controlled bass response
– Separate midrange and treble level controls for tonal adjustment
– Classic Japanese hi-fi loudspeaker design from the early 1980s
