31 May Pioneer TX-3000

Posted at 16:25h in All stock, Tuners by
0 Likes

AM/FM Stereo Tuner

130eur

  • Type: Midi Tuner
  • Years of manufacture: 1978 – 1980
  • Made in: Japan
  • Color: Silver / rarely in black
  • Remote control: no
  • Dimensions: 380 x 83 x 335 mm (WxHxD).
  • Weight: 4 kg
  • Original price approx.: 650 DM


Connections

  • Number of outputs:
    • Output Fix: 650 mV, 4,3 kOhm
  • Number of Inputs:
    • Antenna MW

Antenna VHF 300 Ohm balanced antenna VHF 75 Ohm unbalanced


Technical data

  • Reception: FM, MW
  • Frequencies:
    • VHF: 87.5 – 108 MHz
    • MW: 525 – 1’605 KHz
  • Frequency response: 20 Hz – 15 kHz +/- 0.5 dB
  • Input sensitivity: 1.9 µV IHF
  • Distortion factor:
    • Mono: 0.1 %

Stereo: 0.15

  • Signal-to-noise ratio:
    • Mono: 77 dB

Stereo: 64 dB

  • Channel separation: 45 dB
  • selectivity: 90 dB
  • Co-wave selection: 1.0 dB
  • Spurious wave selection: 60 dB
  • Image frequency attenuation: > 75 dB
  • IF attenuation: > 90 dB
  • AM suppression: 50 dB
